Slim LED Linear Tube
Features
- V-shape patent design 270° aluminum radiator structure
- Human design, 360° rotating end cap with scale,adjust angle and position
- Low heat, less than 50°C
- No UV or IR light radiation,no mercury or other in-organics
- Instant “ON” to 100% brightness
- Worldwide top dimming technology from 0.2%-100% without flickers
- Excellent thermal efficiency
- Works with worldwide electrical systems
- Humidity proof, Dust proof, Shatter proof and Waterproof with IP67 better rating
Previous
Next
| Model No. | WP2K-09WTD-V | WP4K-20WTD-V | WP5K-24WTD-V | WP6K-28WTD-V |
| Norminal Wattage | 9W | 20W | 24W | 28W |
| Dimension(mm) | D28*600mm | D28*1200mm | D28*1500mm | D28*1800mm |
| Weights | 0.36kg | 0.51KG | 0.63KG | 0.75KG |
| Input Voltage AC | AC100-240V/AC100-277V 50/60Hz | |||
| LED Brand | SMD2835 | |||
| Operating Temperature | -40 to +60oC | |||
| Luminarie Efficiency(+/-5%) | 150lm/w | |||
| Dimmable | Triac | |||
| Beam Angle | 150° | |||
| CRI | Ra>80 | |||
| CCT | 2700-6500K | |||
| Rating | IP67,IK08 | |||
| Housing | PC | |||
| Installation | Suspension, Surface mounting | |||
| Warranty | 5 Years | |||
| Lifetime | >50,000h | |||
| Certifications | CE, RoHS | |||
